Finding a high-quality mechanical keyboard that balances price and features has historically been a challenging task for typing enthusiasts and gamers alike. The Ajazz AK820 Pro aims to disrupt this highly competitive market by offering a gasket-mounted, 75% layout mechanical keyboard at an incredibly aggressive price point. Priced at approximately $60 to $70 USD, this peripheral delivers premium features without demanding a premium price tag.
I have spent significant time analyzing this tri-mode keyboard to see how well its engineering holds up against far more expensive competitors in the industry.
Physical Design and Exterior Layout
The physical footprint of this keyboard utilizes a highly popular 75% layout, which successfully saves desktop space while retaining crucial navigation keys and a dedicated function row. Constructed primarily of robust plastic, the chassis weighs in at a lightweight 770 grams, which is approximately 1.7 pounds. On the right side of the front case, an Ajazz logo is subtly engraved, adding a touch of branding to the clean aesthetic. On the rear, the off-centered Type-C port provides a secure wired connection point for charging or latency-free desktop use.
Flipping the device over reveals a highly functional bottom housing designed for daily convenience and ergonomic comfort. Four sturdy rubber feet prevent sliding during intense typing sessions, while two height-adjustable feet allow users to modify the typing angle to three distinct levels. A dedicated magnetic slot securely houses the 2.4 GHz USB wireless dongle to prevent loss during travel. Next to this slot, hardware toggles allow for seamless switching between Windows and Mac OS systems, alongside a physical tri-mode connection switch to cycle between Bluetooth, 2.4 GHz wireless, and wired modes.
The Customizable Smart Screen and Control Knob
A standout physical attribute of this model is the integrated rotary knob and small digital screen positioned just above the arrow cluster. The metal knob offers tactile resistance, letting users control system volume and easily navigate the internal menus of the screen. Out of the box, the miniature display provides critical, at-a-glance information including the current date, time, battery percentage, and active connection mode. Accessing deeper settings directly on the screen allows for quick adjustments to the RGB lighting effects, volume levels, and system language without opening any computer software.
Customization options expand significantly when utilizing the proprietary Ajazz driver companion software. Through the dedicated screen tab in the program, users can upload custom animated GIFs or static images directly from their computers to personalize the display. Larger image files require slightly more time to complete the upload process, but the final visual output looks incredibly vibrant. The software also unlocks deep customization for key remapping, setting up intricate macros across multiple layers, and configuring the per-key RGB backlighting. Enthusiasts will appreciate the reactive audio visualizer mode, which matches the 19 pre-programmed light patterns to whatever sound is playing through your speakers.
Switches, Keycaps, and Stabilizer Performance
This model comes equipped with double-shot PBT keycaps molded in the classic Cherry profile. Measuring 1.3 mm in thickness, these keycaps offer a satisfying texture under the fingertips and possess clean, highly readable legends. The color matching of the set is decent, delivering a premium aesthetic that punches far above its budget-friendly price. Removing these keycaps exposes the pre-lubed Ajazz Gift linear switches, which feature an actuation force of 45 grams and a bottom-out force of 60 grams. These switches glide smoothly right out of the box, thanks to an excellent factory lubrication job.
Customization enthusiasts will find the hot-swappable PCB highly accommodating for aftermarket modifications. The board features a 5-pin hot-swap socket layout configured in a south-facing orientation, ensuring broad compatibility with almost any MX-style switch on the market without keycap interference. The plate-mounted stabilizers are surprisingly outstanding right from the factory, arriving generously lubed to eliminate rattle. Users will not need to waste time modding or tuning these stabilizers, as they perform flawlessly without any additional adjustment.
Internal Gasket Mount Architecture and Acoustic Dampening
Disassembling the keyboard reveals a thoughtful internal structure designed to optimize acoustic performance. Removing the control knob and gently using a plastic pry tool releases the secure clips holding the top and bottom cases together. Inside the housing, a single, delicate wire connects the main printed circuit board to the massive 4,000 mAh internal battery. A comprehensive dampening system resides in the bottom case, starting with a thick layer of case foam and a custom-molded silicon sound dampener that wraps around the battery cavity.
The plate assembly itself is engineered to provide a soft, bouncy typing experience. Ajazz has implemented a polycarbonate plate alongside a PCB that both feature horizontal flex cuts, allowing the board to bend noticeably under pressure. This assembly is cushioned by a PET film, an IXPE switch pad, and a poron plate foam sandwiched between the plate and PCB. Utilizing white silicon gaskets mounted along the edges of the plate, this true gasket structure dampens harsh bottom-out vibrations, producing a deep, pleasing sound signature during fast typing.
Final Thoughts — Price & Value
The Ajazz AK820 Pro establishes a new benchmark for what a budget-oriented mechanical keyboard can deliver. Offering a pre-lubed gasket-mounted structure, a highly customizable TFT screen, and robust tri-mode connectivity for under $70 USD makes it an incredibly compelling purchase.
Anyone searching for a highly functional, great-sounding mechanical keyboard will find this model to be a remarkably solid choice. The combination of pre-lubed linear switches, stable stabilizers, and extensive sound-dampening materials ensures a premium experience without requiring immediate modifications. This peripheral successfully proves that users do not need to spend hundreds of dollars to enjoy a top-tier typing experience.
